| Quantity: | |
|---|---|
| Description： | |
| Items Name | CPVC Socket True Union Ball Valve |
| Material | chlorinated polyvinyl chloride |
| Size | 20~110 mm |
| Color | Light Grey |
| connection | Socket |
| Pressure | Medium Pressure, PN10, PN16, PN35; 150psi, 235psi etc. |
| Structure | on/off |
| Standard | DIN, ANSI, CNS, JIS; NPT, BSPT, BS |
| Certification | ISO14001,ISO9001,SGS,CE, NSF |
| Joints | Thread Joints / Solvent Welding Joints |
| Media | Water/liquid |
| (DIN)VALVE | ||||||||||
| Dimension（mm） | Working Pressure (kg/c㎡) | |||||||||
Size DN （De） | D0 | d0 | d1 | d2 | d | T | H1 | H | L | |
| 15(20) | 51.50 | 27.40 | 20.30 | 19.95 | 15.50 | 17.00 | 26.30 | 82.80 | 95.50 | 10 |
| 20(25) | 59.00 | 32.70 | 25.30 | 24.95 | 20.50 | 19.50 | 30.60 | 92.80 | 109.10 | 10 |
| 25(32) | 70.00 | 41.30 | 32.30 | 31.90 | 26.00 | 23.00 | 39.10 | 109.20 | 122.60 | 10 |
| 32(40) | 85.40 | 49.60 | 40.35 | 39.90 | 33.00 | 27.00 | 44.20 | 131.80 | 147.30 | 10 |
| 40(50) | 98.90 | 60.20 | 50.35 | 49.90 | 39.00 | 32.00 | 52.20 | 143.20 | 158.80 | 10 |
| 50(63) | 122.20 | 76.00 | 63.40 | 62.90 | 51.00 | 38.50 | 71.30 | 175.70 | 182.80 | 10 |
| 65(75) | 158.60 | 89.60 | 75.40 | 74.90 | 64.00 | 44.50 | 82.80 | 231.50 | 234.00 | 10 |
| 80(90) | 192.10 | 105.40 | 90.50 | 89.90 | 81.00 | 52.00 | 99.30 | 260.60 | 255.00 | 10 |
| 100(110) | 223.60 | 128.40 | 110.60 | 109.90 | 99.00 | 62.00 | 115.20 | 292.10 | 297.00 | 10 |
| (ASTM)VALVE | ||||||||||||
| Dimension（mm） | Working Pressure (kg/c㎡) | |||||||||||
Size （*"） | D0 | d0 | d1 | d2 | d3 | d | H1 | H | T | L | M | |
| 1/2" | 51.50 | 30.43 | 20.95 | 18.63 | 16.00 | 15.50 | 26.30 | 82.80 | 17.00 | 95.50 | 1/2" | 10 |
| 3/4" | 59.00 | 36.30 | 26.44 | 24.12 | 20.60 | 20.50 | 30.60 | 92.80 | 19.50 | 109.10 | 3/4" | 10 |
| 1" | 70.00 | 44.61 | 33.25 | 30.29 | 26.00 | 26.00 | 39.10 | 109.20 | 23.00 | 122.60 | 1" | 10 |
| 1-1/4" | 85.40 | 53.87 | 41.91 | 38.95 | 33.00 | 33.00 | 44.20 | 131.80 | 27.00 | 147.30 | 1-1/4" | 10 |
| 1-1/2" | 98.90 | 61.12 | 47.80 | 44.85 | 39.00 | 39.00 | 52.20 | 143.20 | 32.00 | 158.80 | 1-1/2" | 10 |
| 2" | 122.20 | 73.83 | 59.61 | 56.66 | 51.00 | 51.00 | 71.30 | 175.70 | 38.50 | 182.80 | 2" | 10 |
| 2-1/2" | 158.60 | 87.71 | 75.18 | 74.23 | 64.00 | 64.00 | 82.80 | 231.50 | 44.50 | 234.00 | 2-1/2" | 10 |
| 3" | 192.10 | 106.81 | 87.88 | 84.93 | 81.00 | 81.00 | 99.30 | 260.60 | 52.00 | 255.00 | 3" | 10 |
| 4" | 223.60 | 133.46 | 113.03 | 110.07 | 99.00 | 99.00 | 115.20 | 292.10 | 62.00 | 297.00 | 4" | 10 |
| MATERIAL TABLE | ||||
| No. | Parts | Quantity | Material | |
| 01 | Lever | 1 | PVC-U/PP+GF30% | |
| 02 | Shaft | 1 | PVC-U/PVC-C | |
| 03 | Nut | 2 | PVC-U/PVC-C | |
| 04 | Faucet | 2 | PVC-U/PVC-C | |
| 05 | Body | 1 | PVC-U/PVC-C | |
| 06 | Ball | 1 | PVC-U/PVC-C | |
| 07 | Ball seat | 2 | PTFE/TPE+PP | |
| 08 | O-ring1 | 2 | EPDM/FPM | |
| 09 | O-ring2 | 2 | EPDM/FPM | |
| 10 | Seal-Carrier | 1 | PVC-U/PVC-C | |
| 11 | O-ring3 | 1 | EPDM/FPM | |
| 12 | O-ring4 | 2 | EPDM/FPM | |
| Packing Details | |||||||
| No | Description | Size | Pcs/ctn | Weight (g/pcs) | Length (cm) | Width (cm) | Height (cm) |
| 1 | Socket/Threaded True union ball valve | DN15 | 81 | 177.02 | 48.5 | 36 | 32 |
| 2 | DN20 | 60 | 265.73 | 48.5 | 36 | 32 | |
| 3 | DN25 | 57 | 423.67 | 53 | 38 | 38 | |
| 4 | DN32 | 30 | 683.15 | 53 | 38 | 38 | |
| 5 | DN40 | 20 | 1033.52 | 53 | 38 | 38 | |
| 6 | DN50 | 12 | 1720.29 | 53 | 38 | 38 | |
| 7 | DN65 | 6 | 4049.12 | 53 | 37 | 51.5 | |
| 8 | DN80 | 4 | 5850.59 | 57 | 42 | 39 | |
| 9 | DN100 | 2 | 8988.77 | 55 | 45 | 32 | |
| Professional Items: | ||||
| PVC | polyvinyl chloride | |||
| CPVC | chlorinated polyvinyl chloride | |||
| UPVC | unplasticized polyvinyl chlorde | |||
| DIN | Deutsches Institut für Normung e.V. | |||
| ANSI | America National Standard Institute | |||
| JIS | Japanese Industrial Standards | |||
| CNS | Chinese National Standards | |||
| GB | National mandatory national standards | |||
| ISO | International Standards Organization | |||
| AU | Australia Standard | |||
| ASTM | American Society for Testing and Materials | |||
| SGS | Societe Generale de Surveillance S.A. | |||
| NSF | National Sanitation Foundation | |||
1. We can design and produce mould by ourselves, then manufacture each part of the valve, so we have more compatitive price and can guarantee the quality;
2. We provide OEM service and submit Various styles, provide our clients the latest good design;
3. We work with big customers in Middle East, North America, Southeast Asia,Africa;
4. We have standard testing process for the delivery goods;
5. We always provide the gigh quality and professinal service to our customer for so many years, we are experienced iin it.
6. We welcome every youth and peer to our company, thanks for your suggestions and ideas.
show room
Administrators have overseas education background or working experiences, they introduce up-to-date management skills and cutting-edge technologies to the team
Over 200 injection machines, 80 mechanical processing equipment, including machinery imported from Taiwan, Japan and Germany
Huasheng established in 1988 who had over 20 years of experience in plastic extrusion and injection
24-hour Rigorous QC Team that follows ISO 9001 quality management system
A rounded system of up-to-date software and testing equipment for R&D
Equipped with a professional factory, Huasheng Plastic is one of the best manufacturers in China who can offer you cpvc socket true union ball valve din astm manual 1.0mpa for water and chemical industry. We can also offer you the pricelist consultation of cpvc socket true union ball valve din astm manual 1.0mpa for water and chemical industry, welcome to buy our customized products.
