SCH 80 PVC One-Piece Flange
1.Product description : PVC One-Piece Flange
2.Material:UPVC
3.Size:1/2 inch to 8 inch
4.Color: Gray or customize
5.Connect:Socket way
6.Standard:ASTM D 1785 SCH80
7.Certificate:NSF,ISO,SGS
| SCH 80 PVC One-Piece Flange，PVC\CPVC，data specification and drawing | |||||||||||
Item size （*"） | diameter （mm） | ||||||||||
| D0 | D1 | d0 | d1 | d2 | d3 | da | T | H | L | hole number | |
| 1/2" | 89.00 | 60.30 | 29.54 | 21.54 | 21.23 | 17.00 | 16.00 | 23.22 | 13.00 | 27.72 | 4 |
| 3/4" | 89.00 | 69.85 | 35.27 | 26.87 | 26.57 | 22.50 | 16.00 | 26.40 | 14.00 | 30.90 | 4 |
| 1" | 108.00 | 79.38 | 43.66 | 33.66 | 33.27 | 29.00 | 16.00 | 29.57 | 15.00 | 34.10 | 4 |
| 1-1/4" | 117.00 | 88.90 | 53.02 | 42.42 | 42.04 | 38.00 | 16.00 | 32.75 | 15.00 | 38.75 | 4 |
| 1-1/2" | 127.00 | 98.43 | 59.86 | 48.56 | 48.11 | 43.00 | 16.00 | 35.93 | 17.00 | 41.95 | 4 |
| 2" | 152.00 | 120.65 | 72.23 | 60.63 | 60.17 | 55.00 | 19.00 | 39.10 | 19.00 | 46.10 | 4 |
| 2-1/2" | 178.00 | 139.70 | 88.00 | 73.38 | 72.85 | 67.50 | 19.00 | 45.45 | 20.00 | 53.00 | 4 |
| 3" | 191.00 | 152.40 | 105.30 | 89.31 | 88.70 | 83.00 | 19.00 | 48.63 | 20.50 | 57.15 | 4 |
| 4" | 229.00 | 190.50 | 132.00 | 114.76 | 114.07 | 106.00 | 19.00 | 58.15 | 21.00 | 66.65 | 8 |
| 5" | 254.00 | 216.00 | 162.00 | 141.81 | 141.04 | 133.00 | 22.00 | 67.68 | 23.50 | 77.50 | 8 |
| 6" | 284.00 | 241.30 | 190.85 | 168.83 | 168.00 | 160.00 | 22.00 | 77.20 | 26.50 | 88.20 | 8 |
| 8" | 343.00 | 298.45 | 245.84 | 219.84 | 218.69 | 208.00 | 22.00 | 102.60 | 27.00 | 113.60 | 8 |
| Packing List | |||||
| Size | Weight (g/pcs) | Pcs/ctn | Length (cm) | Width (cm) | Height (cm) |
| 1/2" | 98.70 | 175 | 36.00 | 36.00 | 21.00 |
| 3/4" | 131.78 | 144 | 32.00 | 32.00 | 28.00 |
| 1" | 173.78 | 96 | 36.00 | 36.00 | 21.00 |
| 1-1/4" | 206.85 | 84 | 39.00 | 30.00 | 28.50 |
| 1-1/2" | 294.00 | 58 | 36.00 | 36.00 | 26.00 |
| 2" | 427.40 | 45 | 41.00 | 41.00 | 24.00 |
| 2-1/2" | 644.70 | 24 | 43.50 | 31.00 | 30.00 |
| 3" | 761.80 | 30 | 48.50 | 36.00 | 32.00 |
| 4" | 1104.00 | 16 | 42.50 | 42.50 | 28.00 |
| 5" | 1500.30 | 12 | 53 | 38 | 35.5 |
| 6" | 2016.00 | 10 | 53.5 | 44.5 | 30 |
| 8" | 3294.38 | 6 | 65 | 35.5 | 35 |
1.The inquiry will be replied within a workday since we received the inquiry.
2.The samples will be sent out in 3 days in required, but the express charge usually paid by your side, but the fee will be rebound when we have formal order.
3.We send the same quantity products free or send payment back once customers find problem when get goods.
4.We will reply you within a workday and come up with solutions within 5 workdays when we reveive your claim.
show room
Administrators have overseas education background or working experiences, they introduce up-to-date management skills and cutting-edge technologies to the team
Over 200 injection machines, 80 mechanical processing equipment, including machinery imported from Taiwan, Japan and Germany
Huasheng established in 1988 who had over 20 years of experience in plastic extrusion and injection
24-hour Rigorous QC Team that follows ISO 9001 quality management system
A rounded system of up-to-date software and testing equipment for R&D
Equipped with a professional factory, Huasheng Plastic is one of the best manufacturers in China who can offer you sch 80 pvc one piece flange,4 inch normal size. We can also offer you the pricelist consultation of sch 80 pvc one piece flange,4 inch normal size, welcome to buy our customized products.
