DIN CPVC Pipe Clip, Bracket For Industry Area

CPVC Bracket 1.Items Name:CPVC Bracket 2.Material:CPVC 3.Size:20mm to 140mm 4.Color: Gray or customize 5.Connect:Socket 6.Standard: DIN standard 7.Certificate:CE,ISO,SGS

Quantity:
Availability:





Inquire

Product Description

CPVC Flange Fittings Adapter Description：

CPVC Bracket

1.Items Name:CPVC Bracket

2.Material:CPVC

3.Size:20mm to 140mm

4.Color: Gray or customize

5.Connect:Socket

6.Standard: DIN standard

7.Certificate:CE,ISO,SGS

Product Drawing

DIN CPVC Pipe Clip Bracket For Industry Area 1

CPVC Flange Fittings Adapter Size


Clip，PVC-C （DIN PN10） drawing
DN（De）	Measure（mm）
DN（De）	D	H	H1	d	S	L	L1	h1	h2	S1
15(20)	20.20	35.40	27.20	5.20	16.00
20(25)	25.10	41.00	30.50	5.20	16.00
25(32)	32.10	52.80	40.00	5.20	16.00
32(40)	40.10	59.30	44.00	5.20	16.00
40(50)	50.10	71.20	52.00	5.20	16.00
50(63)	63.10	88.50	65.00	5.20	16.00
65(75)	75.10	91.80	62.50	5.20	16.00	82.85	79.11	20.00	26.90	16.00
80(90)	90.10	103.90	69.00	5.20	20.00	97.22	91.87	30.00	36.90	20.00
100(110)	110.10	124.50	85.00	5.20	20.00	105	96.38	30.00	36.90	20.00
125(140)	140.10	154.50	108.00	9.00	25.40

CPVC Flange Fittings Adapter Packing List

Packing list
Size	Pcs/ctn	Weight (g/pcs)	Length (cm)	Width (cm)	Height (cm)
DN15	1200	13	43.5	31	30
DN20	750	16.9	43.5	31	30
DN25	550	21.63	43.5	31	30
DN32	420	30.87	43.5	31	30
DN40	270	42.21	43.5	31	30
DN50	285	55.02	43.5	31	30
DN65	225	87.1	43.5	31	30
DN80	148	110.04	43.5	31	30
DN100	104	156	43.5	31	30

show room

Show Room

Huasheng Advantage

Management:

Administrators have overseas education background or working experiences, they introduce up-to-date management skills and cutting-edge technologies to the team

Machinery:

Over 200 injection machines, 80 mechanical processing equipment, including machinery imported from Taiwan, Japan and Germany

Experience:

Huasheng established in 1988 who had over 20 years of experience in plastic extrusion and injection

Quality Assurance:

24-hour Rigorous QC Team that follows ISO 9001 quality management system

Laboratory:

A rounded system of up-to-date software and testing equipment for R&D

huasheng factory

Equipped with a professional factory, Huasheng Plastic is one of the best manufacturers in China who can offer you din cpvc pipe clip, bracket for industry area. We can also offer you the pricelist consultation of din cpvc pipe clip, bracket for industry area, welcome to buy our customized products.
