SCH 80 CPVC 90 Degree Elbow
1.Items Name: SCH 80 CPVC 90 Degree Elbow
2.Material:CPVC
3.Size:1/2 inch to 12 inch
4.Color: Gray or customize,light Gray
5.Connect: Glue
6.Standard:ASTM F439 SCH80
7.Certificate:NSF,ISO,SGS
1.Environmentally friendly.
2.Provide long service life.
3.Easy to install and handle.
4.Corrosion resistant.
5.Cost effective.
6.Widely accepted by codes.
ASTM D-2846 specifications, have an SDR 11 wall thickness.
The pressure ratings of the CTS SDR 11 systems are 400 psi (pounds per square inch) at 73 F and 100 psi at 180 F.
CPVC plumbing pipe is sold in both straight lengths and (in small diameters) coils.
| 90°elbow，PVC/C，SCH 80 ASTM F439 CPVC fittings drawing | |||||||
| dn（*"） | Size （mm） | ||||||
| D0 | d1 | d2 | d | T | L | H | |
| 1/2" | 30.50 | 21.54 | 21.23 | 17.00 | 23.22 | 36.25 | 51.50 |
| 3/4" | 36.90 | 26.87 | 26.57 | 22.50 | 26.40 | 41.40 | 59.85 |
| 1" | 44.70 | 33.66 | 33.27 | 29.00 | 29.57 | 47.10 | 69.45 |
| 1-1/4" | 54.00 | 42.42 | 42.04 | 38.00 | 32.75 | 55.75 | 82.75 |
| 1-1/2" | 60.60 | 48.56 | 48.11 | 43.00 | 35.93 | 61.95 | 92.25 |
| 2" | 73.10 | 60.63 | 60.17 | 55.00 | 39.10 | 70.85 | 107.40 |
| 2-1/2" | 88.40 | 73.38 | 72.85 | 67.50 | 45.45 | 84.50 | 128.70 |
| 3" | 105.30 | 89.31 | 88.70 | 83.00 | 48.63 | 97.63 | 149.30 |
| 4" | 132.00 | 114.76 | 114.07 | 106.00 | 58.15 | 117.25 | 183.25 |
| 5" | 161.90 | 141.81 | 141.04 | 133.00 | 67.68 | 143.50 | 224.45 |
| 6" | 190.90 | 168.83 | 168.00 | 160.00 | 77.20 | 166.25 | 261.70 |
| 8" | 245.90 | 219.84 | 218.69 | 208.00 | 102.60 | 216.30 | 340.55 |
| 10" | 305.80 | 273.81 | 272.67 | 262.50 | 128.00 | 278.00 | 430.90 |
| 12" | 361.60 | 324.60 | 323.47 | 288.50 | 153.40 | 328.50 | 509.70 |
| Size | Pcs/ctn | Weight (g/pcs) | Length (cm) | Width (cm) | Height (cm) |
| 1/2〞 | 396 | 44.52 | 43.5 | 31 | 30 |
| 3/4〞 | 240 | 70.35 | 43.5 | 31 | 30 |
| 1〞 | 200 | 102.9 | 48 | 36.5 | 30 |
| 1-1/4〞 | 120 | 181.818 | 43 | 34 | 36 |
| 1-1/2〞 | 80 | 208.95 | 39 | 32 | 39 |
| 2〞 | 36 | 306.81 | 45 | 23 | 36 |
| 2-1/2〞 | 36 | 535.5 | 40.5 | 37 | 41.5 |
| 3〞 | 24 | 787.71 | 47 | 47 | 34 |
| 4〞 | 12 | 1540.5 | 41 | 38 | 39 |
| 5〞 | 6 | 2671.5 | 50 | 47 | 25 |
| 6〞 | 4 | 3541.125 | 54 | 40 | 28 |
| 8〞 | 2 | 8216 | 53 | 38 | 38 |
| 10〞 | 1 | 13062.21 | 45 | 33 | 46 |
| 12〞 | 1 | 20431.74 | 54 | 38 | 54 |
show room
Administrators have overseas education background or working experiences, they introduce up-to-date management skills and cutting-edge technologies to the team
Over 200 injection machines, 80 mechanical processing equipment, including machinery imported from Taiwan, Japan and Germany
Huasheng established in 1988 who had over 20 years of experience in plastic extrusion and injection
24-hour Rigorous QC Team that follows ISO 9001 quality management system
A rounded system of up-to-date software and testing equipment for R&D
Equipped with a professional factory, Huasheng Plastic is one of the best manufacturers in China who can offer you sch 80 cpvc pipe elbow 90 degree,4 inch plastic. We can also offer you the pricelist consultation of sch 80 cpvc pipe elbow 90 degree,4 inch plastic, welcome to buy our customized products.
