CPVC Geared Butterfly Valve DIN JIS ASTM Standard Grey Color For Water Supply

CPVC Geared Butterfly Valve DIN JIS ASTM Standard Grey Color For Water Supply

Advantage 1.Soft colors & Compact design; 2.Leakproof operation; 3.Light and falngeconnection make easy installation 4.Economic as cheaper transport charges & long working life 5.Well and high quality control ; 6.Environment friendly, non-toxic;

Description

Description:
The product nameCPVC General Butterfly Valve(Geared Type)
Product materialCPVC/EPDM/natural rubber seal
Product size2"-16"
Product color

Light Grey valve body and red handle; provide other color design

according to customer requirement

The connection methodsflange with gasket
PressurePn10; 1.0Mpa
valve disccpvc
Product standardASTM/CNS/ISO 4422/ANSI/DIN/JIS
CertificationISO14001,ISO9001,SGS,NSF, CE



Dimension (mm)n-Фe

Size of

Turbines

PN(MPa)

Size

(DN)

ФDФD1ФdLФDNL1H1H2H
200342.60 295.00 214.20 76.00 70/102190.00 229.00 299.00 470.00 8-2330:11.00
250409.65 355.00 250.00 85.00 102.00 190.00 264.00 334.00 540.00 12-2250:10.80
300483.55 400.00 290.00 92.00 102.00 190.00 301.50 371.50 613.00 12-2250:10.80
350510.00 450.00 370.00 95.00 102.00 190.00 330.00 410.00 660.00 16-2750:10.60
400570.00 500.00 420.00 95.00 140.00 190.00 360.00 440.00 730.00 16-3050:10.60



Packing Details
NoDescriptionSizePcs/ctn

Weight

(g/pcs)

Length

(cm)

Width

(cm)

Height

(cm)

1

General butterfly valve

(geared type,NR,dark grey)

DN200111303.96 573617
2DN250113453.00 584524
3DN300121091.40 665124
4DN350124995.85 685420
5DN400129348.44 756020

Advantage

1.Soft colors & Compact design;

2.Leakproof operation;

3.Light and falngeconnection make easy installation

4.Economic as cheaper transport charges & long working life

5.Well and high quality control ;

6.Environment friendly, non-toxic;

7.Weathering & Abrasion resistance & excellent chemical resistance

8.Widely used in building,irrigation,industry and swimming pool;

9.Small order acceptable ;

10.Customer's design & logo are welcome

Professional words
PVCpolyvinyl chloride
CPVCchlorinated polyvinyl chloride
UPVCunplasticized polyvinyl chlorde
DINDeutsches Institut für Normung e.V.
ANSIAmerica National Standard Institute
JISJapanese Industrial Standards
CNSChinese National Standards
GBNational mandatory national standards
ISOInternational Standards Organization
AUAustralia Standard
ASTMAmerican Society for Testing and Materials
SGSSociete Generale de Surveillance S.A.
NSFNational Sanitation Foundation

Equipped with a professional factory, Huasheng Plastic is one of the best manufacturers in China who can offer you cpvc geared butterfly valve din jis astm standard grey color for water supply. We can also offer you the pricelist consultation of cpvc geared butterfly valve din jis astm standard grey color for water supply, welcome to buy our customized products.
